dimensions & specifications





in.xe dimensions



in.xe specs




Environmental:

  • Operating temperature:
    North American in.xe models:
    32˚F (0˚C) to 140˚F (60˚C) for pump 1 up to 15 A
    32˚F (0˚C) to 122˚F (50˚C) for pump 1 up to 20 A
    European in.xe.ce models:
    for single-phase system (32 A Max) or 2-phase (2 x 16 A)
    32˚F (0˚C) to 140˚F (60˚C)
    for single-phase system (40 A Max) or 2-phase (2 x 20 A)
    32˚F (0˚C) to 122˚F (50˚C)
    * Controller must be installed under the spa skirt
  • Storage temperature: -13°F (-25°C) to 185°F (85°C)
  • Humidity: Up to 85% RH, non condensing

Mechanical:

  • Weight: 10.5 lb (4.76 kg)
  • Dimensions (W x H x D): 17.38" x 11.75" x 5.1" (441.5 x 298.5 x 129 mm)




UL / CSA standards:

  • UL 1563 Fifth Ed. (2012)
  • UL File: E182156
  • CSA No. 22.2 - 218.1-M89 (2013)


in.xe UL / CSA electrical specifications:

Input rating:

  • 120/240 V nominal (+ 5/- 10 %), 60 Hz (2 lines required with neutral) 48 A Max,
    or
  • 120 V nominal only (+ 5/- 10%), 60 Hz (single line with neutral) 16 A Max.

heat.wav rating:

  • Voltage: 120 or 240 V, 60 Hz
  • Wattage: 5.5 kW at 240 V, 4 kW at 240 V,
    1kW at 120 V
  • Flow rate: Minimum of 18 GPM (68.1 LPM) is required
Output Voltage Maximum current Typical device
output 1 120 / 240 v 20 FLA/70 LRA (in-rush) pump 1 high speed
120 / 240 v 15 FLA/60 LRA (in-rush) pump 1 low speed
output 2* 240 v 15 FLA/60 LRA (in-rush) pump 2
output 3* 120 / 240 v 6 FLA/10 A (cp) / blower
output 4 120 / 240 v 6 FLA/10 A ozone generator
output 5 120 / 240 v 10 A (always ON) audio / video
L1 12 V AC 1 A light
* Available only for the in.xe.5

Important:

  • The maximum power for Outputs 3 to 5 cannot be over 12 A.

TUV standards:

  • EN/IEC 60335 - 1 - 1: /A15:2011 - EN/IEC 60335 - 2 - 60: /A12:2010
  • EN55014-1
  • EN55014-2
  • EN61000-3-2
  • EN61000-3-3


in.xe.ce TUV electrical specifications:

Input rating:

  • 230/400 V nominal (+ 5/- 10 %) (dual-phase system) 20 A Max per phase
    or
  • 230 V nominal (+ 5/- 10 %) (single-phase system) 40 A Max

heat.wav rating:

  • Voltage: 230 V, 50 Hz
  • Wattage:
    3,8 kW at 230 V
    2 kW at 230 V1,3 kW at 230 V
  • Flow rate: A minimum of 18 GPM (68,1 LPM) is required
Output Voltage Maximum current Typical device
output 1 230 v 15 FLA/60 LRA (in-rush) pump 1 high - low
output 2* 230 v 15 FLA/60 LRA (in-rush) pump 2
output 3* 230 v 6 FLA/10 A (cp) / blower
output 4 230 v 6 FLA/10 A ozone generator
output 5 230 v 10 A (always ON) audio / video
L1 12 V AC 1 A light
* Available only for the in.xe.5

The in.xe.ce is lab tested to IPx5 enclosure protection levels.

IPx5 level of waterproofing is conditional on 3 items:

  • Both front covers (heater and input wiring) are closed and screwed shut.
  • A suitable waterproof strain-relief/bushing is used for the cable entry into the pack.
  • Any unused in.link connection (HC, LC, or low voltage) is plugged with the appropriate blank plug.
